Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Name | Digital RCD (ELCB) Tester |
| Brand | UNI-T |
| Model Number | UT582+ |
| Device Type | Residual Current Device (RCD) Tester |
| Supply Voltage Range | 195V – 253V |
| Voltage Measurement Range | 30V – 600V (45Hz – 65Hz) |
| Display | 999-count LCD with backlight |
| RCD Test Currents | 10mA / 20mA / 30mA / 100mA / 300mA / 500mA |
| Trip Time Settings | 40ms / 300ms / 1000ms / 2000ms |
| Trip Time Accuracy | ±(2% + 2) |
| Phase Angle Selection | 0° and 180° |
| AUTO RAMP Function | 20%–110% step testing (10% increments) |
| Voltage Accuracy | ±(3% + 3) |
| Resolution | 1V |
| Safety Category | CAT III 600V |
| Safety Standards | IEC 61010, IEC 61557, EN61326 |
| Key Functions | Trip time & current measurement, data hold, LCD backlight |
| Protection Features | Fuse protection, disconnect buzzer, mis-operation buzzer, over-range display (OL) |
| Power Supply | 6 × 1.5V AA (LR6) batteries |
| Low Battery Indication | < 7.2V |
| Auto Power Off (APO) | Supported |
| Display Features | Full icon display, backlight, data hold |
| Connections Check | Simultaneous trip time & trip current testing |
| Product Dimensions | 160 × 100 × 71 mm |
| Weight | 400 g |
| Product Color | Red & Grey |
| Accessories Included | Test leads, carrying bag, elastic strap |
| Packaging | Gift box with English manual |
| Applications | Electrical safety testing, RCD/ELCB verification, industrial and residential electrical inspection |
Package Includes:
- 1 x Uni-T UT582+ Digital RCD (ELCB) Tester
- 1 x Test leads
- 1 x Carrying bag
- 1 x Elastic strap
- User manual
