Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Series | UNI-T UT200 Series (UT206B / UT207B / UT208B) |
| Display | 6000-count LCD with analog bar (31 segments) |
| Measurement Technology | True RMS |
| Auto Range | Yes |
| Safety Rating | CAT III 1000V / CAT IV 600V |
| Certifications | CE / ETL |
| Jaw Opening | 42 mm |
| Design | Clamp-type digital multimeter |
Measurement Ranges
| PARAMETER | RANGE | ACCURACY |
|---|---|---|
| AC Current | Up to 1000A | ±(2% + 5) |
| DC Current | Up to 1000A | ±(2% + 5) |
| Inrush Current | Up to 1000A | ±(10% + 10) |
| AC Voltage | Up to 1000V | ±(1.2% + 3) |
| DC Voltage | Up to 1000V | ±(0.5% + 5) |
| Resistance | Up to 60MΩ | ±(1% + 2) |
| Capacitance | Up to 60mF | ±(4% + 5) |
| Frequency | 10Hz – 1MHz | ±(0.1% + 3) |
| AC Frequency Response | 40Hz – 400Hz | — |
| Duty Cycle | 10% – 90% | ±(2.6% + 7) |
Build & Hardware
| CATEGORY | SPECIFICATIONS |
|---|---|
| Jaw Size | 42 mm opening |
| Display Type | Large LCD with backlight |
| Operation | Auto ranging digital system |
| Power Features | Low power consumption design |
Package Includes:
- 1 x Clamp Meter
- 1 x Test Lead
- 1 x Cloth Bag
- 1 x Manual
