Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Type | Ethernet Network Module |
| Chipset | W5500 |
| Communication Interface | SPI (Mode 0, 3) |
| Network Protocols | TCP, UDP, ICMP, IPv4, ARP, IGMP, PPPoE |
| Sockets Support | 8 independent sockets |
| Ethernet Speed | 10/100 Mbps (10BaseT / 100BaseTX) |
| Memory Buffer | 32 KB (TX/RX buffers) |
| Operating Voltage | 3.3V (5V I/O tolerant) |
| Duplex Mode | Full / Half duplex (auto negotiation) |
| Power Modes | Power down mode supported |
| Wake Function | Wake on LAN (UDP) supported |
| LED Indicators | Link, Speed, Full/Half duplex, Active |
| Package Type | 48-pin LQFP (7 × 7 mm, 0.5 mm pitch) |
| Board Size | 55 × 28 mm |
| Color | Blue |
| Key Features | High-speed Ethernet communication, stable TCP/IP stack, SPI-based MCU integration |
| Applications | Embedded networking, IoT devices, industrial communication systems |
Package Includes:
1 x W5500 Module
