Smart Bot 2WD Wheel Chassis

(No reviews yet) Write a Review

SKU:: PEMSR48
UPC:
MPN:
Shipping:: Calculated at Checkout

TZS23,023.30

Current Stock:

Quantity:

Frequently bought together:

Description
0 Reviews

Description

Features:

Mechanical structure is simple, it is easy to install.
This car is the tachometer encoder.
Can be used for distance measurement.
Can use with other devices to realise function of tracing, obstacle avoidance, distance testing, speed testing, wireless remote control.

Motor Parameters
Voltage	DC 3V	DC6V	DC 7.2V
Current	160mA	220mA	250mA
No-load Speed	120 rpm/min	200 rpm/min	250 rpm/min
Load Speed	100 rpm/min	175 rpm/min	210 rpm/min
Torque	0.45 kg.cm	1.0 kg.cm	1.5 kg.cm
Reduction Ratio	1:48
Noise	≤65dB
Motor Size	65mm x 18mm x 22mm(LWH)

_{Smart Robot Car Parameters}
Voltage	3~9V	Drive Mode	2WD
Current	600mA	Chassis Thickness	3mm
Load	≤2kg	Car Weight	285g
Speed	0.6 m/s	Car Size	220 x 175 x 65mm

Package Includes:

A car chassis
Trolley wheels x 2
DC Gear Motor x 2
Speed encoder x 2
Fasteners x 4
Caster x 1
Four batteries box x 1
A high-quality rocker switch
An assembly drawing
Several screws and nuts
