Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Type | ESP32 Development Board |
| Module | ESP-WROOM-32 |
| USB Interface | Micro USB (via CP2102 USB-to-Serial) |
| Wireless Connectivity | Wi-Fi 802.11 b/g/n + Bluetooth 4.2 (BR/EDR & BLE) |
| Processor | Dual-core 32-bit CPU |
| Clock Speed | Up to 240 MHz |
| Performance | Up to 600 DMIPS |
| Flash Memory | 32 Mbit SPI Flash |
| Operating Voltage | 5V (USB) / 5V–12V (VIN pin) |
| Power Consumption | ~300 mA @ 3.3V |
| GPIO Pins | 22 I/O pins |
| Interfaces Supported | UART, SPI, I2C, PWM, I2S, IR, SDIO, ADC, DAC |
| On-chip Sensors | Hall sensor, temperature sensor, capacitive touch |
| Serial Baud Rate | 115200 bps (default) |
| Wi-Fi Frequency Range | 2.4 GHz (2412–2484 MHz) |
| Antenna | Onboard PCB antenna (2 dBi gain) |
| Transmit Power | Up to ~17 dBm (802.11b) |
| Receiving Sensitivity | Down to -90 dBm (1 Mbps) |
| Security | WPA / WPA2 / WPA2 Enterprise / WPS |
| Operating Modes | STA, AP, STA+AP |
| Power Modes | Multiple sleep modes (deep sleep ~6.5 µA) |
| Indicators | Power LED (red), Status LED (blue) |
| Control Buttons | Reset and Boot (program mode) |
| Programming Support | NodeMCU, Arduino, AT commands, OTA (FOTA) |
| Debug Support | OpenOCD |
| Operating Temperature | -20°C to +85°C |
| Storage Conditions | -40°C to +90°C, <90% RH |
| Dimensions | 52 × 29 × 15 mm |
| Key Features | High performance, integrated Wi-Fi & Bluetooth, USB programming |
| Applications | IoT, home automation, wireless control, industrial monitoring, smart devices |
Package Includes:
1 X ESP32 Development Board
