CAG-002 Mechatronics Training System (7-station)

(No reviews yet) Write a Review
SKU:
CAG-002
Shipping:
Calculated at Checkout
  • CAG-002 Mechatronics Training System (7-station)
  • CAG-002 Mechatronics Training System (7-station)
$0.00
Frequently bought together:

Description

CAG-002 Mechatronics Training System (7-station)

* This is a comprehensive mechatronic training and simulation system, it offers a complete solution for the study of modern factory automation and integrates a variety of technological applications, including mechanical & electrical & electronic & information & sensor technologies, etc.

* Industrial grade components and control methods are used to fully demonstrate the factory production line system, up to seven stations are built on the platform, including feeding unit, transfer unit, drilling unit, stopper and transit unit, sorting unit, triaxial handling unit, horizontal storage unit.
* The input and output signal cables of each actuator are led to serial ports, at the same time, all the  power lines are gathered on one seat, by this way to achieve quick connection of the whole system and ensure the safe pluggable ability for practical operation.
* When the serial ports of controller panel and I/O panel are connected, user can upload the standard programs to run the system process directly for demonstration purpose without further operation.
* When conducting the independent design and programming training, by disconnecting the serial port to achieve an open control mode, all wiring can be done through the 4mm safety sockets with pluggable cables.
* The experiment panel adopts modular design, coming with standard height that can easily be inserted into the frame area. The complete unit is movable and lockable, with complete aluminium profile structure.

TRAINING CONTENT
Mechanical Structure Application

* Biaxial cylinder and guide slot formed material blanking mechanism
* DC motor and conveyor belt formed transfer mechanism
* Biaxial cylinder and DC gear motor formed drilling simulation mechanism
* Sensor and storage unit formed warehouse with data feedback function
* Servo motor, ball screw, stepping motor and synchronous belt guide rail formed cantilever type carrier

Pneumatic Structure Application

* Bus board
* Cylinder
* Solenoid valve
* Direction & Speed & Sequence control

Electrical Control Application
* System I/O, digital quantity, high speed quantity, extended module
* Limit sensor, photoelectric sensor, fiber optic sensor, metal sensor, magnetic sensor and color mark sensor
* Power supply module, controller module and interface module
* Servo driver, stepping driver
* Single solenoid and double solenoid valves

Programming Application

* Sequential structure, selective structure and cycle structure
* Switching value realized cylinder motion control, DC motor control, conveyor start/stop control, indicator control
* Pulse value realized stepping motor control, servo motor control
