ATMEGA32 AVR Embedded Trainer - Order Code 43504

SPECIFICATION

1. CPU: ATMEL Atmega32 Microcontroller
2. ISP Programming facility

1. 8 LEDs to display Digital Output
2. 8 Switches to give Digital Input each indicated by LED
3. 16*2 Alphanumeric LCD
4. 4 digit Seven segment displays
5. I2C compatible
   1. 24C512 EEPROM (64KB)
   2. DS1307 RTC with suitable battery
   3. 4 Ch. 8bit ADC & 8 bit DAC using PCF8591
6. Temperature sensor interface Lm35
7. Temperature sensor interface DS18B20
8. 24 I/O Lines Provided on a 26 pin FRC Connector for external interface
9. On board supply /- 12V, 5V is provided
10. Supply Input Voltage: 230VAC
11. User's Manual with sample programs for all on board features.
