OpenBuilds V-Slot Large T-Gantry Plate DIY Kit

The OpenBuilds V-Slot Build Board DIY Kit is a mechanical motion assembly designed for V-Slot linear rail systems. It consists of a large T-Gantry plate, precision spacers (isolation columns), V-wheels with integrated bearings, mounting hardware, and spacers. The kit is commonly used in CNC machines, 3D printers, laser engravers, automation equipment, and custom linear motion projects to create smooth and reliable movement along OpenBuilds V-Slot aluminum extrusions.

Features

• Durable aluminum T-Gantry plate for structural strength and stability.
• Compatible with OpenBuilds V-Slot linear motion systems.
• Precision V-wheels with pre-installed 625 bearings for smooth operation.
• Isolation column spacer ensures proper wheel alignment and spacing.
• Easy-to-assemble design for DIY and professional projects.
• Supports accurate linear movement with minimal friction.
• Suitable for custom machine building and automation applications.
• Includes mounting hardware for quick installation.

Specifications

T-Gantry Plate

• Type: OpenBuilds Slider Gantry Plate (Large)
• Material: Aluminum Alloy
• Dimensions: 127 mm × 88 mm × 3 mm

Isolation Column (Spacer)

• Compatible with: OpenBuilds Systems
• Bore Diameter: 5.1 mm
• Outer Diameter: 10 mm
• Height: 6 mm
• Material: Metal Spacer

Plastic V-Wheel with Bearings

• Wheel Type: OpenBuilds Plastic V-Wheel
• Bore Diameter: 5 mm
• Bearing Type: 625 Bearing
• Bearings Included: Yes
• Quantity: 4 Pieces

Fasteners

• Screw Size: M4.5 × 25 mm
• Quantity: 4 Pieces

Applications

This kit can be used in:

• CNC router gantry assemblies
• 3D printer motion systems
• Laser engraving machines
• Camera sliders and motion control systems
• Automated production equipment
• Robotics and mechatronics projects
• DIY linear actuator systems
• Educational STEM and engineering projects
• Custom machine-building applications

Package includes

• 1 × Large OpenBuilds T-Gantry Plate (127 × 88 × 3 mm)
• 1 × Isolation Column Spacer
• 4 × Plastic V-Wheels with 625 Bearings
• 4 × M4.5 × 25 mm Mounting Screws
• 4 × Copper Spacers
