DSO211 1MHz 10MSa/ Mini ARM Storage Oscilloscope
(No reviews yet)
Write a Review
- SKU:
- PEOOS87
- Shipping:
- Calculated at Checkout
Frequently bought together:
Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Name | Pocket Digital Storage Oscilloscope |
| Series / Model | DSO Series (DS212 upgrade version of DS202) |
| Device Type | Open-source ARM-based portable digital oscilloscope |
| Processor Platform | ARM Cortex-M3 (32-bit) |
| Channels | 2 Channels |
| Display | 2.8-inch full-color TFT LCD (320 × 240 resolution) |
| Control Interface | Dual gear control knob system |
| Portability | Pocket-size compact design |
| Operating Concept | Open hardware + open firmware (hackable DIY platform) |
| Storage | Built-in 8 MB flash storage + USB flash disk support |
| File Formats Supported | BMP, DAT, BUF, CSV |
| Waveform Saving | Internal storage + USB export |
| USB Interface | Micro USB (data + charging) |
| Power Supply | Built-in 500 mAh rechargeable lithium battery |
| Battery Charging | Micro USB charging |
| Battery Life | Portable field-use endurance (typical short session use) |
| Signal Generator (Built-in) | Yes |
| Signal Generator Range | 10 Hz – 1 MHz (square wave, adjustable duty cycle) |
| Waveform Generator Types | Sine, Square, Triangle, Sawtooth (10 Hz – 20 kHz for analog waveforms) |
| Trigger Modes | Auto, Normal, Single, Scan, None |
| Trigger Type | Rising edge, Falling edge |
| Measurement Functions | Frequency, period, duty cycle, DC RMS, Vpp, Vmax, Vmin, Vavg |
| Math Functions | -A, -B, A+B, A−B, Rectified A/B/C waveforms |
| Sampling Modes | Vertical precision, horizontal precision, trigger threshold control |
| Waveform Analysis | Real-time signal observation and math processing |
| Data Export Features | Waveforms and images saved as BMP, DAT, BUF, CSV |
| Storage Capacity | 8 MB internal waveform storage |
| Signal Generator Output | Square, sine, triangle, sawtooth |
| Sync Modes | Auto, Normal, Single, Scan |
| Control Features | Side thumbwheel control interface |
| Compliance | CE / FCC certified |
| Applications | Electronics repair, education labs, embedded systems, field maintenance, automotive electronics, communication debugging |
| Special Features | Open-source hardware/firmware, DIY hackable STM32 development platform |
Package Includes:
1 x DS212 Mini Pocket Portable Oscilloscope
