Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Type | 24GHz Microwave Radar Motion Sensor Module |
| Operating Principle | Doppler radar motion detection using microwave reflection |
| Operating Frequency | 24 GHz (24.125 GHz typical, 24–24.25 GHz range) |
| Output Power | ~16 dBm (typical), ~5 mW radiated power |
| Operating Voltage | ~5.5 V (typical) |
| Operating Current | 30 mA typical, 40 mA max |
| Operating Temperature | -20 °C to +60 °C |
| Detection Range | Up to 15 m |
| Detection Method | Motion detection via microwave signal reflection (Doppler shift) |
| Signal Output | IF analog output: -300 mV to +300 mV |
| Pulse Width | ~10 µs |
| Antenna / Channel Design | Independent transmit and receive channels for high gain and sensitivity |
| Penetration Ability | Can penetrate non-metallic materials (glass, wood, plastic, fabric) |
| Environmental Immunity | Not affected by temperature, humidity, dust, airflow, light, or noise |
| Interference Resistance | Strong RF immunity, stable operation in harsh environments |
| Physical Size | 25 mm × 25 mm × 7 mm |
| Sensitivity | High sensitivity and fast response |
| Installation Notes | Avoid magnetic fields, moving conductors, exposed harsh environments |
| Key Features | Long-range detection, small size, high stability, low power, strong penetration capability |
| Applications | Smart lighting, security systems, industrial automation, motion detection, people counting, smart buildings, surveillance systems |
Package Includes:
1 x Microwave 24GHz Human Body Sensor
