Raspberry Pi GPS Module USB Port

Raspberry Pi GPS Module models A, B, A +, B +, Zero, 2. USB Port – GPS module contains T CP202USB serial interface chip, through a serial Port or USB and Raspberry Pi to communicate.
GPS Module USB Port is integrated with the Patch antenna (5.0 * 5.0 * 5.0 mm) of compact modules, with ultra-low power consumption, the advantages of fast positioning, capturing, and tracking, make the USB Port–GPS have a very good performance.

Specifications:

• Item Type: GPS Module
• Channels: 22 (tracking) / 66 (capturing)
• Input Voltage (V): 3.3 to 5
• Working Current: Max 100mA
• GPS Mode: L80-39
• Location Precision: 2.5m CEP
• Speed Precision: 0.1 m/s
• Capturing Sensitivity: -148dm
• Tracking Sensitivity (dBm): -165dm
• Data Format: NMEA0183 protocol
• Operating Temperature (°C): -40 to 85
• Aerial Size: 15 x 15 x 4 mm
• Material: Plastic
• Color: Red

Features:

• Suitable For Raspberry Pi A B A+ B+ Zero 2 3.

• Connect via 1*8 2.54 separation distance pin header or USB micro data cable.

• Adopting L80-39 mold project, with 15 x 15 x 4mm Patch aerial.

• Super low power consumption, quick location.

• Support Short-circuit Protection and Aerial Detection.

• Support self-auxiliary AGPS (EASY technology), no need for external memory.

• Support LOCUS, DGPS, SBAS(WAAS/EGNOS/MSAS/GAGAN).

Package Included:

1 x Raspberry Pi GPS Module USB Port
