Study of Electro-magnetic Induction and Verification of Faraday’s Laws - Order Code 55732

SPECIFICATION

1. Cal ibration of Wattmeter us ing DC Potentiometer (Crompton Potentiometer)

1. Crompton Potentiometer
2. Digital Electronic Standard Cell.
3. Digital Electronic DC Null Detector.
4. Potentiometer Power Supply : (2V/4V at 2Amp.)  This gives fixed IC regulated outputs 2 and 4 Volt DC at Amp. with over loadand short circuit protection.
5. Power Supply for Calibration of Wattmeter Using Crompton Potentiometer (0 - 300 DC at 20 mA, Fixed 1V5 at 5Amp.)
6. Volt Ratio Box with DPDTSwitch.
7. Moving Iron AC portable Wattmeter (Dynamometer type):Housed in bakelite case with knife edge pointer & anti parallax mirror scale of 140mm length, spring controlled movement, having accuracy class 1.0.Single phase , multi range , current coil 5/10Amp.Potential coil 75/150/300 Volt.
8. Standard Resistance Box.
9. Standard Resistance Box.
10. The unit is operative on 230 V at 50Hz AC Mains.
11. Adequate no. of patch cords stackable 4 mm spring loaded plug length 50cm.
12. Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms.
13. Strongly supported by detailed OperatingInstructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
14. Weight : 9 Kg. (Approx.)
