Microprocessor Device Controller - Order Code 52045

(No reviews yet) Write a Review

SKU:: 52045
UPC:
MPN:
Shipping:: Calculated at Checkout

KES0.00

Current Stock:

Quantity:

Description
0 Reviews

Description

Order Code: 52045
Name: Microprocessor Device Controller

SPECIFICATION

Introduction
This unit has been designed to train the students to handle basic input - output operations of the 8085 microprocessor through 8255 ports. The power supply, drivers and other hardware are pre-wired resulting in a greater reliability of operation. The students are expected to enter a few suggested programs and also to develop their own programs for a variety of input-output operations.

Experiments

Light the 8 LEDs in a cycle, in binary sequence, as a bar graph display etc.
Operate the 2 relays with software controlled timing
Operate the 7-segment display through segment control
Sense the state of the 4-switches as input and send out suitable signals to various output devices
Study of SID/SOD commands

Features and Specifications

System comprises of a main unit and a mp kit
The main unit houses all the I/O devices, viz. LED’s, relays, 7-segment display, switches and their drivers/interfacing circuits
The status of the relays and switches are displayed with the help of lamps mounted on the panel
Supporting literature with experiment details
