Hydraulic Trainer (Advanced) - Order Code 52287

SPECIFICATION

1. Compact Ergonomic Design.
2. ISO Symbol for each mounted components.
3. User Friendly, Self Explanatory Systems.
4. Leak proof Safety Measures, sturdy piping & Robust Construction.
5. Training Manuals mimic Charts for Operation Ease.
6. System Frame with Caster Wheel Arrangement for ease in movement.
7. M.S. powder coated cubical plant with standard Instrument Mountings.
8. Inbuilt Safety Measures to avoid improper usage
9. Wall mounting assemblies of hydraulic actuator & self-reciprocating cylinder.
10. Hydraulic motor & Hydraulic Accumulator.
11. QRC couplings provided, Tubing for circulation of pressure (Hose Pipe Tubing)
12. Manifold for distribution.
13. Oil Hydraulic power pack for power supply.
14. Flow measuring device provided on the kit.
15. Optional component are available to allow fault operation and diagnosis training.

1. Study of fundamental principles of Hydraulics & its applications.
2. Study of Meter-in Circuit & Meter-out circuit.
3. Study of Bleed-off Circuit.
4. Study of Transverse & Feed Circuit.
5. Study of sequencing operation using Pressure Sequence Valve.
6. Study of Speed Control, Pressure Control & Flow Control.
7. Study of Direction Control.
8. Study of Hydraulic valves
9. Study of Hydraulic Actuators.
10. Study of Hydraulic Power Pack.
11. Study of Hydraulic Accumulator & Hydraulic Motor.
12. Study of operation of Telescopic Cylinder (Optional).
13. Study of operation of Limited Rotary Actuator (Optional).
14. Study of flow rate measurement for speed control circuit

1. Electric supply 1φ 230 V AC / 3φ supply of 415 V, 50 Hzsuitably used for direct on line starting of an induction motor
