Description

Order Code: 43215
Name: 8051 Microcontroller Trainer (LCD)

SPECIFICATION

43215 is a single board Microcontroller Trainer Kit based on 8 bit 8051 Microcontroller, which is widely used to train engineers to develop on software/hardware for any industrial process & control. Kit has power-full Monitor EPROM, RAM, I/O Lines, Timer/Counter, Serial, LCD Display, Keyboard for Man to Machine Interface.

Features

16K Bytes of EPROM with 32K bytes of Battery Backup RAM.
48 I/O Lines, Three Channel Timer/Counter, PC Serial Interface using USART, 12 bit ADC, DAC, RTC. 5 20x2
LCD Display with 101 ASCII Keyboard.
Power-full Command like Single Stepping, Break Point, Full Clock Execution, Examine Memory/ Registor.
Uploading & Downloading to and from PC in Windows98/XP/NT.
In-Built Power Supply.

Specifications

8051/89C52/89C51RD2/89C61X2 CPU operating @11.0592MHz.
32K user RAM using 6264 with Battery Backup using NICD Battery.
One socket is provided for RAM expansion up to 64K.
16K bytes of powerful monitor EPROM using 27512.
48 I/O lines using 2 Nos. of 8255 brought at 26 Pins FRC Connector to interface with IC-XX Series.
Three Channel Timer/Counter using 8253.
20x2/40x2/20x4 Alphanumeric LCD Display with Backlite
