TESCA

6264/6116 RAM Study Card + FRC - Order Code 43284

(No reviews yet) Write a Review
SKU:
43284
Shipping:
Calculated at Checkout
UGX0.00
Frequently bought together:

Description

Order Code: 43284
Name: 6264/6116 RAM Study Card + FRC

SPECIFICATION

Study Cards can be connected to the 50 Pins KXT Bus of any 8/16 bit Series Microprocessor Trainer Kits. In this Study Card LED's are provided for different signals like Read, Write, Address Lines, Data Lines, Chip Select & Ports depending upon the Peripherals. Study

6116/6264/62256 RAM STUDY CARD
  • Data lines from AD0 to AD7 are indicated by 3mm LEDs.
  • Chip Select, Read, Write are indicated by 3mm LEDs.
  • Hardware Single Step and Full Clock Execution modes are provided.
  • Single stepping can be performed using micro switch provided on board.
  • Using this study card all MODE experiment can be Performed
  • Interface 8085/8086 Kit using 50 pin FRC Connector.
  • User's Manual with Sample Programs.
