Order Code: 38616
Name: Logic Training Board on Counters & Shift Registers
SPECIFICATION
Computer Logic Training Board has been designed specifically for the study of Counters & Shift Registers to make the student familiar with the design and practical aspects of all types of counters, shift registers and their applications in frequency measurements and computers etc. This board with gates and Flip-Flops can be used to construct any type of counter, shift register etc. and the output of each circuit can also be observed in decimal code with the help of decoder and Seven Segment Display. More than 25 experiments can be conducted on this training board. These experiments cover several aspects of computer, input and output devices, memories, arithmetic and control units. Once the student understands these basic circuits, he can combine them in infinite varieties of complex circuits.
Practical experience on this board carries great educative value for Science and Engineering Students.
Object:
To design, fabricate and test the following:
(A) COUNTERS
Practical experience on this board carries great educative value for Science and Engineering Students.
Object:
To design, fabricate and test the following:
(A) COUNTERS
- Ripple Counters:
- 4-Stage binary ripple up-counter.
- 4-Stage binary ripple down-counter.
- 4-Stage binary ripple up-down counter.
- Variable modules ripple counter by direct clearing.
- 4-Stage decade ripple up-counter by direct clearing.
- 4-Stage decade ripple down counter by direct clearing.
- Synchronous Counters:
- 4-Stage binary synchronous up-counter with parallel carry.
- 4-Stage binary synchronous down-counter with parallel carry.
- 4-Stage binary synchronous up-counter with series carry.
- 4-Stage binary synchronous down-counter with series carry.
- 4-Stage binary synchronous up-down counter with parallel carry.
- 4-Stage synchronous up-down counter with series carry.
- 4-Stage synchronous decade counter with parallel carry.
- Series Parallel Counters:
- 3-Stage mod-5 series parallel counter.
- 4-Stage mod-10 series parallel counter.
- Ring Counter:
- 4-Stage ring counter.
- Johnson Counters:
- 4-Stage Johnson or shift counter.
- Decade counter using 5-stage shift counter.
- Miscellaneous Counters:
- Higher Modules counter by combining two lower modules counter.
- 2421 BCD counter.
(B) SHIFT REGISTERS
To study the operation of:
- Serial to parallel converter.
- Series-in-series output register.
- Parallel to serial converter.
- Parallel-in-parallel out register.
- Right shift and left-shift register.
(C) APPLICATION OF COUNTERS
- To study the basic principle of frequency measurement.
- To study the operation of frequency division by counter.
- To study the principle of Random Access Memory by constructing its basic cell.
