ECG Amp.12 Leads Selector +USB BioWave Order Code - BM2105

SPECIFICATION

ECG Amplifier 12 leads Selector with USB
ECG Amplifier 12 Leads with selector switch Trainer Kit
12 leads real time amplified. ECG output up to 10Vpp±
I, II, III, aVR, aVL, aVF, V1 to V6 Chest lead, Standard Unipolar and Bipolar Leads
Gain adjustable, Self Test Clamp & Suction Electrodes.DSO o/p through 4mm socket
Test point on the top of instrument through 2mm socket.
Power Supply 230 ±10%, 50Hz, Dimensions 250 X 75 X 250 mm±

Study on ECG Amplifier
Measuring the electrical activity generated by the heart. Different Lead combination lead. Study of normal abnormal ECG waves. & signal processing Placement of Electrodes, Amplification, Filters, Gain, Self test, Voltage, Frequency responses, etc.

BIOWAVE Software
Software for measurement of ECG single. Measurement of Voltage, Time & Frequency of each point. Setting Voltage & Time Expand the signal, Save as, Open, Print, etc. For advance study Excel values, offset setting, etc.

Other Models
SN.    Order Code     Name of Item
01.     BM2101     ECG Amp. 3 Leads
02.     BM2102     ECG Amp. 12 Leads Selector
03.     BM2103     ECG Amp. 12 Leads with Simulator
04.     BM2104     ECG Amp. 3 Lead with Heart Rate + Hi-Lo
05.     BM2105     ECG Amp. 12 Leads Selector with USB
06.     BM2106     ECG Amp. 3 Leads with Plethysmograph
07.     BM2501     ECG Simulator Portable
08.     BM2502     ECG Simulator Table Model
09.     BM2503     ECG Arrhythmias Simulator 12L, 15A

Operating Manual with working of instrument, operating & installation procedure, Block diagrams, connection diagrams, Electrodes placement, Standard signals & actual output signal, Calculations, Tables, Trouble shooting, Experiments list & etc.
