Op-Amp Applications with power supply and 1 meters - Order Code 36247

SPECIFICATION

1. Square Wave generator.
2. Pulse & Ramp generator.
3. Triangular Generator.
4. Sine Wave Generator using Wien Bridge, Phase Shift Network.
5. Active Filters :
   • Low Pass Filter.
   • High Pass Filter.
   • Band Pass Filter.
   • Notch Filter.
6. Voltage Regulators.
7. Null Detector.
8. D.C. Microammeter.

1. ±15V D.C at 25mA, IC Regulated Power Supply.
2. 0-20V D.C at 100mA, continuously variable Power Supply.
3. D.C. Milliammeter, 65mm rectangular dial to read 0-1mA.
4. Two OP-AMP IC's 741.
5. Three Linear Potentiometers.
6. Two Zener Diodes and adequate no. of other electronic components
7. Mains ON/OFF switch, Fuse and Jewel light.
8. The unit is operative on 230V ±10% at 50Hz A.C. Mains.
9. Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre.
10. Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections / observation of waveforms.
11. Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
