Emitter Follower (CC) with power supply - Order Code 36122

SPECIFICATION

Experimental Training Board has been designed specifically to study over all characteristics of the Emitter Follower Amplifier.

Object:
To study the over all characteristics of the Emitter Fol lower Amplifier and to find :

1. Voltage Gain.
2. Input Impedance.
3. Output Impedance.

Features:
The board consists of the following built-in parts :

• 9V D.C. at 50mA, IC regulated Power Supply internally connected.
• NPN transistor.
• Adequate no. of other electronic components.
• Mains ON/OFF switch, Fuse and Jewel light.
• The unit is operative on 230V ±10% at 50Hz A.C. Mains.
• Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre.
• Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms.
• Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References.
• Weight : 3 Kg. (Approx.)
• Dimension : W 340 x H 110 x D 210
