Description
Features:
| CATEGORY | SPECIFICATIONS |
|---|---|
| Product Type | XL52832-D01 Bluetooth Module |
| Chipset | Nordic nRF52832 |
| Bluetooth Version | Bluetooth 4.2 |
| Core Processor | ARM Cortex-M4F |
| Supported Protocols | Bluetooth Smart (BLE), ANT, ANT+, Proprietary 2.4GHz |
| Frequency Range | 2360 – 2483 MHz |
| Modulation Method | GFSK |
| Output Power | +4 dBm |
| Receiver Sensitivity | -96 dBm |
| Transmission Current | 5.3mA @ 0dBm |
| Receiving Current | 5.3mA @ 1Mbps |
| Deep Sleep Current | 0.4µA |
| RAM | 64KB |
| Flash Memory | 512KB |
| Antenna Type | Onboard antenna with external IPEX antenna support |
| Interface Spacing | 1.27 mm |
| Module Dimensions | 21 × 25 mm |
| Processing Features | Floating-point arithmetic support |
| Applications | IoT devices, wireless sensors, BLE communication, wearable electronics, smart devices |
| Key Features | Low power consumption, multi-protocol support, Cortex-M4F processing core, onboard and external antenna support |
Package Includes:
1 x NRF52832 Bluetooth 4.2 Low Power Module
