ZE08-CH2O Formaldehyde sensor

(No reviews yet) Write a Review
SKU:
PEFSS62
Weight:
0.05 KGS
Shipping:
Calculated at Checkout
KES3,000.00

Description

High sensitivity, high resolution
- Low power consumption
- Support various output: UART, PWM, analog voltage signal and so on
- High stability, superior anit-interval ability:
- Application: air quality sensor, ventilation system, air conditioner.
Specification:
- Output data: DAC(0.4-2V standard voltage signal); UART output(3V level)
- Working voltage: 3.7-9V(with reverse polarity protection)
- Warming-up time<= 3 min
- Respond time: <= 60s
- Recovery time:<= 60s
- Sense range: 0-5mg/ m3
- Resolution: <= 0.01ppm
- Working temperature: 0~50 degree
- Working humidify: 15~90%RH (no condensing)
- Storage temperature: 0~50 degree.
