868MHz/915MHz LoRa ESP32 Oled WiFi SX1276 Module

(No reviews yet) Write a Review
SKU:
PELRN99
Shipping:
Calculated at Checkout
  • 868MHz/915MHz LoRa ESP32 Oled WiFi SX1276 Module
  • 868MHz/915MHz LoRa ESP32 Oled WiFi SX1276 Module
  • 868MHz/915MHz LoRa ESP32 Oled WiFi SX1276 Module
KES3,900.00

SOLD OUT

Description

Description:
WIFI Kit series is the new development of the cost-effective networking program, the main chip using ESP32, LX6 dual-core processor, computing power up to 600DMIPS, chip built-in 520 KB SRAM, 802.11 b / g / N HT40 Wi-Fi transceiver, baseband, protocol stack and LWIP, integrated dual-mode Bluetooth (traditional Bluetooth and BLE low power Bluetooth).
This product is based on the WIFI Kit 32 added SX1276 chip, that is, LoRa trade remote modem, Applicable frequency:868MHz  frequency, about -148dBm high sensitivity, +20 dBm power output, high reliability, transmission distance (measured open area communication distance 2.6Km).
Onboard 32MByte Flash, Wi-Fi antenna, 0.96-inch blue OLED display, lithium battery charging circuit and interface, CP2102 USB to serial chip, the perfect support for Arduino development environment, can be very simple and fast for program verification and product development.

Technical Parameters
Dominant Frequency: 240MHZ
Flash: 8Mbyte
Processor: Tensilica LX6 Dual Core
Master chip: ESP32
LoRa chip: SX1276
Support frequency band: 868-915MHZ
Open communication distance: 2.8KM
Computing capacity: up to 600DMIPS
Dual-mode Bluetooth: traditional Bluetooth and BLE low-power Bluetooth
Development environment: perfect support for Arduino
Operating voltage: 3.3-7V
Operating temperature range: -40-90 ℃
Receiver sensitivity: -139dbm (SD12, 125KHz)
UDP continuous throughput: 135Mbps
USB adapter chip: CP2102
Support mode: Sniffer, Station, softAP and Wi-Fi Direct

Document link : https://github.com/HelTecAutomation/Heltec_ESP32

U.FL IPEX to SMA Connector Antenna 868MHz  915MHZ for Lora Board Lora32u4 II Wifi Lora32
Connector type: ipex
Band definition: 868MHz / 915MHz
Standing wave ratio: <= 1.5
Gain: 3dBi
Maximum power: 10W
Input impedance: 50Omega

Package Includes
1pc x 868MHz/915MHz LoRa ESP32 Oled Wifi SX1276 Module
1pc x Antenna

868MHz/915MHz LoRa ESP32 Oled Wifi SX1276 Module IOT with Antenna For Arduinos Electronic Diy Kit
