12V 100mm stroke 900N high speed linear actuator

(No reviews yet) Write a Review
SKU:
PERTS77
Weight:
2.95 KGS
Shipping:
Calculated at Checkout
  • 12V 100mm stroke 900N high speed linear actuator
  • 12V 100mm stroke 900N high speed linear actuator
KES4,500.00

Description

Features :
This miniature linear actuator is using for industrial, agricultural machinery, construction, clean sweeping vehicles, vessels, cargo and many other applications.
It can be replaced by hydraulic, pneumatic products ideal for saving energy consumption.


Specification :
Drive voltage: 12VDC
Maximum Thrust: 90KG/900N
Minimum installation size (fully retracted around in the middle of the distance between the two holes): L1= Stroke+105 mm
Maximum installation size (fully extended around the middle of the distance of the two holes): L = 2xS(stroke)+105mm
Ambient temperature :-26  to +65 degree
Protection class: IP 54
Built-in limit switches(When completed stroke, linear actuator automatically stops!)
Low noise design, noise levels below 42 db
Work rule: 10%. Loading rated thrust need 10% work rule. In 20 minutes, 2minutes work 18minutes rest.            If lower load can extend work time.
Maximum self-locking force 2300N
Speed: 12mm/s
Stroke Length: 100mm / 4 inch
Working frequency: 20%
Built-in limit switches, not adjustable after leave factory.


Package included :
1 x 900N 100mm Linear Actuator Motor

Details pictures :













More Detailed Photos:

12V 900N 4 Inch 100mm Linear Actuator Adjustable Actuator Tor Opener Linear Actuator Motor
12V 900N 4 Inch 100mm Linear Actuator Adjustable Actuator Tor Opener Linear Actuator Motor
12V 900N 4 Inch 100mm Linear Actuator Adjustable Actuator Tor Opener Linear Actuator Motor
12V 900N 4 Inch 100mm Linear Actuator Adjustable Actuator Tor Opener Linear Actuator Motor
12V 900N 4 Inch 100mm Linear Actuator Adjustable Actuator Tor Opener Linear Actuator Motor
