ST-LINK/V2 Debugger EMULATOR

• 5 V power supplied by a USB connector
• USB 2.0 full-speed-compatible interface
• USB standard A to Mini- B cable

SWIM Specific Features:

• 1.65 V to 5.5 V application voltage supported on SWIM interface
• SWIM low-speed and high-speed modes supported
• SWIM programming speed rate: 9.7 Kbytes/s in low speed and 12.8 Kbytes/s in high speed
• SWIM cable for connection to the application via an ERNI standard vertical connector (ref: 284697 or 214017) or horizontal connector (ref: 214012)
• SWIM cable for connection to the application via a pin header or a 2.54 mm pitch connector

JTAG/serial wire debugging (SWD) specific features:

• 1.65 V to 3.6 V application voltage supported on the JTAG/SWD interface and 5 V tolerant inputs
• JTAG cable for connection to a standard JTAG 20-pin pitch 2.54 mm connector
• JTAG supported
• SWD and serial wire viewer (SWV) communication supported
• Direct firmware update feature supported (DFU)
• Status LED which blinks during communication with the PC
• Operating temperature 0 to 50 °C
• 1000 Vrms high isolation voltage (ST-LINK/V2-ISOL only

Package Includes:

• ST-LINK V2 Emulator
• Mini USB T-plug cable
• FRC cable with 20 pin connector
• Dual Female connectors
