Description
- 42 mm x 42 mm x 48 mm (L x W x H)
- Step Angle: 1.8 degrees
- Resistance: 1.65 Ω
- Current/Phase: 1.68 A
- Voltage: 2.8 V
- Holding Torque: 43 Ncm
- Inductance/Phase: 2.3 mH +/- 20% (1 kHz)
- Weight: 340 g
- Attached cable: 80 cm, bare wire
- Shafts: Round
- Shaft Diameters: 5 mm
- Front Shaft Length: 22 mm
- Rear Shaft Length: 10mm
- Bipolar, 4 leads
Package Contents:
- Dual Shaft NEMA17 stepper motor (JK42HS48-1684B)
